Name Type Description
STNDZRV BOOLEAN Start in any phase or phases from zone RV - any
direction
STND BOOLEAN Fault detected in any phase or phases - any
direction
STNDL1 BOOLEAN Fault detected in phase L1 - any direction
STNDL2 BOOLEAN Fault detected in phase L2 - any direction
STNDL3 BOOLEAN Fault detected in phase L3 - any direction
STNDPE BOOLEAN Fault with earth connection detected in any phase
or phases - any direction
STFWL1 BOOLEAN Fault detected in phase L1 - forward direction
STFWL2 BOOLEAN Fault detected in phase L2 - forward direction
STFWL3 BOOLEAN Fault detected in phase L3 - forward direction
STFWPE BOOLEAN Fault with earth connection detected - forward
direction
STRVL1 BOOLEAN Fault detected in phase L1 - reverse direction
STRVL2 BOOLEAN Fault detected in phase L2 - reverse direction
STRVL3 BOOLEAN Fault detected in phase L3 - reverse direction
STRVPE BOOLEAN Fault with earth connection detected - reverse
direction
STFW1PH BOOLEAN Single-phase fault detected - forward direction
STFW2PH BOOLEAN Two-phase fault detected - forward direction
STFW3PH BOOLEAN Three-phase fault detected - forward direction
STPE BOOLEAN Ph-E zone measurement enabled - any direction
STPP BOOLEAN Ph-Ph zone measurement enabled - any direction
6.1.5 Settings
PID-7066-SETTINGS v1
Table 34: ZMFPDIS Non group settings (basic)
Name
Values (Range) Unit Step Default Description
GlobalBaseSel 1 - 12 - 1 1 Selection of one of the Global Base
Value groups
ZDbRepInt 1 - 100000 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
ZMax 0.0 - 5000.0 Ohm 0.1 1500.0 Maximum value in ohm
ZRepTyp Cyclic
Dead band
Int deadband
Dead band & 5s
Cyclic
Dead band & 30s
Cyclic
Dead band & 1min
Cyclic
- - Cyclic Reporting type
ZAngDbRepInt 1 - 100000 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
1MRK 506 382-UEN A Section 6
Impedance protection
Line distance protection REL650 2.2 IEC 91
Technical manual
