ABB REL650 - Settings

Name Type Description
G1AI3 GROUP SIGNAL Group 1 analog input 3
G1AI4 GROUP SIGNAL Group 1 analog input 4
G1N GROUP SIGNAL Group parameter for residual sample
PID-3406-INPUTSIGNALS v6
Table 614: SMAI2 Input signals
Name Type Default Description
BLOCK BOOLEAN 0 Block group 2
REVROT BOOLEAN 0 Reverse rotation group 2
GRP2L1 STRING - First analog input used for phase L1 or L1-L2
quantity
GRP2L2 STRING - Second analog input used for phase L2 or L2-L3
quantity
GRP2L3 STRING - Third analog input used for phase L3 or L3-L1
quantity
GRP2N STRING - Fourth analog input used for residual or neutral
quantity
PID-3406-OUTPUTSIGNALS v5
Table 615: SMAI2 Output signals
Name
Type Description
G2AI3P GROUP SIGNAL Group 2 analog input 3-phase group
G2AI1 GROUP SIGNAL Group 2 analog input 1
G2AI2 GROUP SIGNAL Group 2 analog input 2
G2AI3 GROUP SIGNAL Group 2 analog input 3
G2AI4 GROUP SIGNAL Group 2 analog input 4
G2N GROUP SIGNAL Group parameter for residual sample
19.8.4 Settings
SEMOD55783-1 v2
SEMOD130357-4 v3
Settings DFTRefExtOut and DFTReference shall be set to default
value InternalDFTRef if no VT inputs are available. Internal
nominal frequency DFT reference is then the reference.
Section 19 1MRK 506 382-UEN A
Basic IED functions
822 Line distance protection REL650 2.2 IEC
Technical manual
