supervised with four settable limits: low-low limit, low limit, high limit and high-
high limit. The measure value expander block (RANGE_XP) has been introduced
to enable translating the integer output signal from the measuring functions to 5
binary signals: below low-low limit, below low limit, normal, above high limit or
above high-high limit. The output signals can be used as conditions in the
configurable logic or for alarming purpose.
14.8.3 Function block
SEMOD54336-4 v3
IEC05000346-2-en.vsd
RANGE_XP
RANGE* HIGHHIGH
HIGH
NORMAL
LOW
LOWLOW
IEC05000346 V2 EN-US
Figure 315: RANGE_XP function block
14.8.4 Signals
SEMOD53803-1 v2
PID-3819-INPUTSIGNALS v5
Table 434: RANGE_XP Input signals
Name
Type Default Description
RANGE INTEGER 0 Measured value range
PID-3819-OUTPUTSIGNALS v5
Table 435: RANGE_XP Output signals
Name
Type Description
HIGHHIGH BOOLEAN Measured value is above high-high limit
HIGH BOOLEAN Measured value is between high and high-high
limit
NORMAL BOOLEAN Measured value is between high and low limit
LOW BOOLEAN Measured value is between low and low-low limit
LOWLOW BOOLEAN Measured value is below low-low limit
14.8.5 Operation principle
SEMOD52462-4 v5
The input signal must be connected to a range output of a measuring function block
(CVMMXN, CMMXU, VMMXU, VNMMXU, CMSQI, VMSQ or MVGAPC).
The function block converts the input integer value to five binary output signals
according to
table 436.
1MRK 506 382-UEN A Section 14
Monitoring
Line distance protection REL650 2.2 IEC 621
Technical manual
