16.2.4 Monitored data
PID-6818-MONITOREDDATA v2
Table 470: SCHLCCH Monitored data
Name
Type Values (Range) Unit Description
GatewayConfig INTEGER 0=Ok
1=Error
-1=Off
2=Invalid
-
Gateway configuration
status
PID-6819-MONITOREDDATA v2
Table 471: RCHLCCH Monitored data
Name Type Values (Range) Unit Description
GatewayConfig INTEGER 0=Ok
1=Error
-1=Off
2=Invalid
-
Gateway configuration
status
PID-6813-MONITOREDDATA v4
Table 472: FRONTSTATUS Monitored data
Name
Type Values (Range) Unit Description
GatewayConfig INTEGER 0=Ok
1=Error
-1=Off
2=Invalid
-
Gateway configuration
status
16.3 Redundant communication
16.3.1 Identification
GUID-B7AE0374-0336-42B8-90AF-3AE1C79A4116 v1
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
IEC 62439-3 Parallel redundancy
protocol
PRP - -
IEC 62439-3 High-availability seamless
redundancy
HSR - -
Access point diagnostic for redundant
Ethernet ports
RCHLCCH - -
