ABB REL650 - Function Block; Signals

sources for maintenance issues, lower system reliability and an extended purchase
portfolio. The selector switch function eliminates all these problems.
11.5.3 Function block
SEMOD114954-4 v6
SLGAPC
BLOCK
PSTO
UP
DOWN
^P01
^P02
^P03
^P04
^P05
^P06
^P07
^P08
^P09
^P10
^P11
^P12
^P13
^P14
^P15
^P16
^P17
^P18
^P19
^P20
^P21
^P22
^P23
^P24
^P25
^P26
^P27
^P28
^P29
^P30
^P31
^P32
SWPOSN
IEC14000005-1-en.vsd
IEC14000005 V1 EN-US
Figure 209: SLGAPC function block
11.5.4 Signals
PID-6641-INPUTSIGNALS v3
Table 230: SLGAPC Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
PSTO INTEGER 0 Operator place selection
UP BOOLEAN 0 Binary "UP" command
DOWN BOOLEAN 0 Binary "DOWN" command
1MRK 506 382-UEN A Section 11
Control
Line distance protection REL650 2.2 IEC 415
Technical manual
