Name Type Default Description
STDIR4 INTEGER 0 Start direction input 4
STDIR5 INTEGER 0 Start direction input 5
STDIR6 INTEGER 0 Start direction input 6
STDIR7 INTEGER 0 Start direction input 7
STDIR8 INTEGER 0 Start direction input 8
STDIR9 INTEGER 0 Start direction input 9
STDIR10 INTEGER 0 Start direction input 10
STDIR11 INTEGER 0 Start direction input 11
STDIR12 INTEGER 0 Start direction input 12
STDIR13 INTEGER 0 Start direction input 13
STDIR14 INTEGER 0 Start direction input 14
STDIR15 INTEGER 0 Start direction input 15
STDIR16 INTEGER 0 Start direction input 16
PID-6906-OUTPUTSIGNALS v2
Table 280: SMAGAPC Output signals
Name Type Description
STDIR INTEGER Common start direction output
13.2.5 Settings
PID-6906-SETTINGS v2
Table 281: SMAGAPC Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
13.2.6 Operation principle
GUID-02403756-5715-4D6B-9308-540D72979BD0 v2
Start matrix
The Start Matrix function requires that a protection function delivers the directional
output signals in a fixed order to Start Matrix.
A directional input signal STDIRX of the Start Matrix is of type word. Each input
contains 14 individual Boolean signals, which are positioned as, see Figure
247.
STDIRX
=[
b0, b1, b2, b3, b4, b5, b6, b7, b8, b9, b10, b11, b12, b13, b14
]
b0= START (start)
b1= FW (forward)
b2= REV (reverse)
Table continues on next page
Section 13 1MRK 506 382-UEN A
Logic
474 Line distance protection REL650 2.2 IEC
Technical manual
