13.7.10.2 Signals
PID-3817-INPUTSIGNALS v2
Table 333: XOR Input signals
Name
Type Default Description
INPUT1 BOOLEAN 0 Input 1 to XOR gate
INPUT2 BOOLEAN 0 Input 2 to XOR gate
PID-3817-OUTPUTSIGNALS v2
Table 334: XOR Output signals
Name Type Description
OUT BOOLEAN Output from XOR gate
NOUT BOOLEAN Inverted output from XOR gate
13.7.10.3 Technical data
GUID-0B07F78C-10BD-4070-AFF0-6EE36454AA03 v1
Table 335: Number of XOR instances
Logic block
Quantity with cycle time
3 ms 8 ms 100 ms
XOR 10 10 20
13.8 Fixed signals FXDSIGN
13.8.1 Identification
SEMOD167904-2 v2
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Fixed signals FXDSIGN - -
13.8.2 Functionality
M15322-3 v12
The Fixed signals function (FXDSIGN) has nine pre-set (fixed) signals that can be
used in the configuration of an IED, either for forcing the unused inputs in other
function blocks to a certain level/value, or for creating certain logic. Boolean,
integer, floating point, string types of signals are available.
One FXDSIGN function block is included in all IEDs.
1MRK 506 382-UEN A Section 13
Logic
Line distance protection REL650 2.2 IEC 503
Technical manual
