17.8.13.3 Function block
GUID-6EC8453E-0D00-4720-95A6-156C41CA46BB v1
IEC10000285-1-en.vsd
I103GENCMD
BLOCK ^CMD_OFF
^CMD_ON
IEC10000285 V1 EN-US
Figure 372: I103GENCMD function block
17.8.13.4 Signals
PID-3970-INPUTSIGNALS v5
Table 550: I103GENCMD Input signals
Name Type Default Description
BLOCK BOOLEAN 0 Block of command
PID-3970-OUTPUTSIGNALS v5
Table 551: I103GENCMD Output signals
Name Type Description
CMD_OFF BOOLEAN Command output OFF
CMD_ON BOOLEAN Command output ON
17.8.13.5 Settings
PID-3970-SETTINGS v5
Table 552: I103GENCMD Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
PulseLength 0.000 - 60.000 s 0.001 0.400 Pulse length
InfNo 1 - 255 - 1 1 Information number for command output
(1-255)
17.8.14 IED commands with position and select for IEC
60870-5-103 I103POSCMD
17.8.14.1 Functionality
GUID-1E40B94D-B6A6-42F0-8757-A47B8A3FA3CD v7
I103POSCMD is a transceiver function that monitors activity on its input signals
and interprets any state transition into commands then sent over an established IEC
60870-5-103 link. Additionally, it listens for general interrogation (GI) requests
and replies to those with a GI response message with the current state of each
connected input.
