ABB REL650 - Signals; Monitored Data; Settings

13.9.4 Signals
PID-3606-INPUTSIGNALS v4
Table 337: B16I Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
IN1 BOOLEAN 0 Input 1
IN2 BOOLEAN 0 Input 2
IN3 BOOLEAN 0 Input 3
IN4 BOOLEAN 0 Input 4
IN5 BOOLEAN 0 Input 5
IN6 BOOLEAN 0 Input 6
IN7 BOOLEAN 0 Input 7
IN8 BOOLEAN 0 Input 8
IN9 BOOLEAN 0 Input 9
IN10 BOOLEAN 0 Input 10
IN11 BOOLEAN 0 Input 11
IN12 BOOLEAN 0 Input 12
IN13 BOOLEAN 0 Input 13
IN14 BOOLEAN 0 Input 14
IN15 BOOLEAN 0 Input 15
IN16 BOOLEAN 0 Input 16
PID-3606-OUTPUTSIGNALS v3
Table 338: B16I Output signals
Name
Type Description
OUT INTEGER Output value
13.9.5 Monitored data
PID-3606-MONITOREDDATA v4
Table 339: B16I Monitored data
Name
Type Values (Range) Unit Description
OUT INTEGER - - Output value
13.9.6 Settings
ABBD8E283673 v3
The function does not have any parameters available in the local HMI or PCM600.
Section 13 1MRK 506 382-UEN A
Logic
506 Line distance protection REL650 2.2 IEC
Technical manual
