13.7.7.3 Settings
PID-3811-SETTINGS v5
Table 321: RSMEMORY Group settings (basic)
Name
Values (Range) Unit Step Default Description
Memory Off
On
- - On Operating mode of the memory function
13.7.7.4 Technical data
GUID-BE6FD540-E96E-4F15-B2A2-12FFAE6C51DB v1
Table 322: Number of RSMEMORY instances
Logic block Quantity with cycle time
3 ms 8 ms 100 ms
RSMEMORY 10 10 20
13.7.8 Set-reset with memory function block SRMEMORY
IP11020-1 v2
M11485-3 v4
The Set-reset with memory function block (SRMEMORY) is a flip-flop with
memory that can set or reset an output from two inputs respectively. Each
SRMEMORY function block has two outputs, where one is inverted. The memory
setting controls if, after a power interruption, the flip-flop resets or returns to the
state it had before the power interruption. The input SET has priority.
Table 323: Truth table for SRMEMORY function block
SET
RESET OUT NOUT
0 0 Last
value
Inverted
last value
0 1 0 1
1 0 1 0
1 1 1 0
13.7.8.1 Function block
M11484-3 v2
SRMEMORY
SET
RESET
OUT
NOUT
IEC04000408_2_en.vsd
IEC04000408 V2 EN-US
Figure 261: SRMEMORY function block
