17.4.4 Technical data
IP14434-1 v1
M15031-1 v8
Table 480: Communication protocols
Function
Value
Protocol IEC 61850-8-1
Communication speed for the IEDs 100BASE-FX
Protocol IEC 60870–5–103
Communication speed for the IEDs 9600 or 19200 Bd
Protocol DNP3.0
Communication speed for the IEDs 300–115200 Bd
Protocol TCP/IP, Ethernet
Communication speed for the IEDs 100 Mbit/s
Protocol LON
Communication speed for the IEDs 1.25 Mbit/s
Protocol SPA
Communication speed for the IEDs 300–38400 Bd
17.4.5 Generic communication function for Single Point indication
SPGAPC, SP16GAPC
SEMOD55999-1 v4
17.4.5.1 Functionality
SEMOD55713-5 v8
Generic communication function for Single Point indication (SPGAPC) is used to
send one single logical signal to other systems or equipment in the substation.
17.4.5.2 Function block
SEMOD54714-4 v4
SPGAPC
BLOCK
^IN
IEC14000021-1-en.vsd
IEC14000021 V1 EN-US
Figure 341: SPGAPC function block
Section 17 1MRK 506 382-UEN A
Station communication
674 Line distance protection REL650 2.2 IEC
Technical manual
