14.6.6 Monitored data
PID-3949-MONITOREDDATA v2
Table 429: DRPRDRE Monitored data
Name
Type Values (Range) Unit Description
MemoryUsed INTEGER - % Memory usage (0-100%)
UnTrigStatCh1 BOOLEAN - - Under level trig for
analog channel 1
activated
OvTrigStatCh1
BOOLEAN - - Over level trig for analog
channel 1 activated
UnTrigStatCh2 BOOLEAN - - Under level trig for
analog channel 2
activated
OvTrigStatCh2
BOOLEAN - - Over level trig for analog
channel 2 activated
UnTrigStatCh3 BOOLEAN - - Under level trig for
analog channel 3
activated
OvTrigStatCh3
BOOLEAN - - Over level trig for analog
channel 3 activated
UnTrigStatCh4 BOOLEAN - - Under level trig for
analog channel 4
activated
OvTrigStatCh4
BOOLEAN - - Over level trig for analog
channel 4 activated
UnTrigStatCh5 BOOLEAN - - Under level trig for
analog channel 5
activated
OvTrigStatCh5
BOOLEAN - - Over level trig for analog
channel 5 activated
UnTrigStatCh6 BOOLEAN - - Under level trig for
analog channel 6
activated
OvTrigStatCh6
BOOLEAN - - Over level trig for analog
channel 6 activated
UnTrigStatCh7 BOOLEAN - - Under level trig for
analog channel 7
activated
OvTrigStatCh7
BOOLEAN - - Over level trig for analog
channel 7 activated
UnTrigStatCh8 BOOLEAN - - Under level trig for
analog channel 8
activated
OvTrigStatCh8
BOOLEAN - - Over level trig for analog
channel 8 activated
UnTrigStatCh9 BOOLEAN - - Under level trig for
analog channel 9
activated
OvTrigStatCh9
BOOLEAN - - Over level trig for analog
channel 9 activated
Table continues on next page
