Name Type Values (Range) Unit Description
UnTrigStatCh10 BOOLEAN - - Under level trig for
analog channel 10
activated
OvTrigStatCh10
BOOLEAN - - Over level trig for analog
channel 10 activated
UnTrigStatCh11 BOOLEAN - - Under level trig for
analog channel 11
activated
OvTrigStatCh11
BOOLEAN - - Over level trig for analog
channel 11 activated
UnTrigStatCh12 BOOLEAN - - Under level trig for
analog channel 12
activated
OvTrigStatCh12
BOOLEAN - - Over level trig for analog
channel 12 activated
UnTrigStatCh13 BOOLEAN - - Under level trig for
analog channel 13
activated
OvTrigStatCh13
BOOLEAN - - Over level trig for analog
channel 13 activated
UnTrigStatCh14 BOOLEAN - - Under level trig for
analog channel 14
activated
OvTrigStatCh14
BOOLEAN - - Over level trig for analog
channel 14 activated
UnTrigStatCh15 BOOLEAN - - Under level trig for
analog channel 15
activated
OvTrigStatCh15
BOOLEAN - - Over level trig for analog
channel 15 activated
UnTrigStatCh16 BOOLEAN - - Under level trig for
analog channel 16
activated
OvTrigStatCh16
BOOLEAN - - Over level trig for analog
channel 16 activated
UnTrigStatCh17 BOOLEAN - - Under level trig for
analog channel 17
activated
OvTrigStatCh17
BOOLEAN - - Over level trig for analog
channel 17 activated
UnTrigStatCh18 BOOLEAN - - Under level trig for
analog channel 18
activated
OvTrigStatCh18
BOOLEAN - - Over level trig for analog
channel 18 activated
UnTrigStatCh19 BOOLEAN - - Under level trig for
analog channel 19
activated
OvTrigStatCh19
BOOLEAN - - Over level trig for analog
channel 19 activated
Table continues on next page
