13.3 Trip matrix logic TMAGAPC
IP15121-1 v4
13.3.1 Identification
SEMOD167882-2 v3
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Trip matrix logic TMAGAPC - -
13.3.2 Functionality
M15321-3 v12
The trip matrix logic TMAGAPC function is used to route trip signals and other
logical output signals to different output contacts on the IED.
The trip matrix logic function has 3 output signals and these outputs can be
connected to physical tripping outputs according to the specific application needs
for settable pulse or steady output.
