ABB REL650 - Settings; Technical Data; Inverter Function Block INV; Function Block

PID-3801-OUTPUTSIGNALS v5
Table 302: GATE Output signals
Name Type Description
OUT BOOLEAN Output from gate
13.7.2.3 Settings
PID-3801-SETTINGS v6
Table 303: GATE Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
13.7.2.4 Technical data
GUID-45DF373F-DC39-4E1B-B45B-6B454E8E0E50 v2
Table 304: Number of GATE instances
Logic block Quantity with cycle time
3 ms 8 ms 100 ms
GATE 10 10 20
13.7.3 Inverter function block INV
IP11011-1 v2
13.7.3.1 Function block
M11445-3 v1
IEC04000404_2_en.vsd
INV
INPUT OUT
IEC04000404 V2 EN-US
Figure 256: INV function block
13.7.3.2 Signals
PID-3803-INPUTSIGNALS v5
Table 305: INV Input signals
Name
Type Default Description
INPUT BOOLEAN 0 Input
PID-3803-OUTPUTSIGNALS v4
Table 306: INV Output signals
Name
Type Description
OUT BOOLEAN Output
