Table 239: Description of the input-output relationship
VALID OPEN CLOSE
POSITION
Value Description
0 - - 0 Intermediate
1 0 0 0 Intermediate
1 1 0 1 Open
1 0 1 2 Closed
1 1 1 3 Bad State
11.8 Single point generic control 8 signals SPC8GAPC
SEMOD176448-1 v3
11.8.1 Identification
SEMOD176456-2 v3
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Single point generic control 8 signals SPC8GAPC - -
11.8.2 Functionality
SEMOD176462-4 v10
The Single point generic control 8 signals (SPC8GAPC) function block is a
collection of 8 single point commands that can be used for direct commands for
example reset of LEDs or putting IED in "ChangeLock" state from remote. In this
way, simple commands can be sent directly to the IED outputs, without
confirmation. Confirmation (status) of the result of the commands is supposed to
be achieved by other means, such as binary inputs and SPGAPC function blocks.
The commands can be pulsed or steady with a settable pulse time.
11.8.3 Function block
SEMOD176479-4 v5
SPC8GAPC
BLOCK
PSTO
^OUT1
^OUT2
^OUT3
^OUT4
^OUT5
^OUT6
^OUT7
^OUT8
IEC07000143-3-en.vsd
IEC07000143 V3 EN-US
Figure 213: SPC8GAPC function block
Section 11 1MRK 506 382-UEN A
Control
424 Line distance protection REL650 2.2 IEC
Technical manual
