ABB REL650 - Function Block; Signals

11.10.3 Function block
SEMOD116040-4 v2
IEC05000698-2-en.vsd
SINGLECMD
BLOCK ^OUT1
^OUT2
^OUT3
^OUT4
^OUT5
^OUT6
^OUT7
^OUT8
^OUT9
^OUT10
^OUT11
^OUT12
^OUT13
^OUT14
^OUT15
^OUT16
IEC05000698 V3 EN-US
Figure 215: SINGLECMD function block
11.10.4 Signals
PID-6189-INPUTSIGNALS v6
Table 246: SINGLECMD Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block single command function
PID-6189-OUTPUTSIGNALS v6
Table 247: SINGLECMD Output signals
Name
Type Description
OUT1 BOOLEAN Single command output 1
OUT2 BOOLEAN Single command output 2
OUT3 BOOLEAN Single command output 3
OUT4 BOOLEAN Single command output 4
OUT5 BOOLEAN Single command output 5
OUT6 BOOLEAN Single command output 6
OUT7 BOOLEAN Single command output 7
OUT8 BOOLEAN Single command output 8
OUT9 BOOLEAN Single command output 9
OUT10 BOOLEAN Single command output 10
OUT11 BOOLEAN Single command output 11
OUT12 BOOLEAN Single command output 12
OUT13 BOOLEAN Single command output 13
OUT14 BOOLEAN Single command output 14
OUT15 BOOLEAN Single command output 15
OUT16 BOOLEAN Single command output 16
Section 11 1MRK 506 382-UEN A
Control
430 Line distance protection REL650 2.2 IEC
Technical manual
