17.8.9.5 Settings
PID-6485-SETTINGS v5
Table 540: I103USRDEF Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 5 Function type (1-255)
InfNo1 1 - 255 - 1 1 Information number for binary input 1
(1-255)
InfNo2 1 - 255 - 1 2 Information number for binary input 2
(1-255)
InfNo3 1 - 255 - 1 3 Information number for binary input 3
(1-255)
InfNo4 1 - 255 - 1 4 Information number for binary input 4
(1-255)
InfNo5 1 - 255 - 1 5 Information number for binary input 5
(1-255)
InfNo6 1 - 255 - 1 6 Information number for binary input 6
(1-255)
InfNo7 1 - 255 - 1 7 Information number for binary input 7
(1-255)
InfNo8 1 - 255 - 1 8 Information number for binary input 8
(1-255)
TypNo1 Absolute
Relative
- - Absolute Type identification (TYP)
TypNo2 Absolute
Relative
- - Absolute Type identification (TYP)
TypNo3 Absolute
Relative
- - Absolute Type identification (TYP)
TypNo4 Absolute
Relative
- - Absolute Type identification (TYP)
TypNo5 Absolute
Relative
- - Absolute Type identification (TYP)
TypNo6 Absolute
Relative
- - Absolute Type identification (TYP)
TypNo7 Absolute
Relative
- - Absolute Type identification (TYP)
TypNo8 Absolute
Relative
- - Absolute Type identification (TYP)
GiNo1 Excluded
Included
- - Included Response and status change (GI)
GiNo2 Excluded
Included
- - Included Response and status change (GI)
GiNo3 Excluded
Included
- - Included Response and status change (GI)
GiNo4 Excluded
Included
- - Included Response and status change (GI)
GiNo5 Excluded
Included
- - Included Response and status change (GI)
Table continues on next page
1MRK 506 382-UEN A Section 17
Station communication
Line distance protection REL650 2.2 IEC 751
Technical manual
