Name Values (Range) Unit Step Default Description
GiNo6 Excluded
Included
- - Included Response and status change (GI)
GiNo7 Excluded
Included
- - Included Response and status change (GI)
GiNo8 Excluded
Included
- - Included Response and status change (GI)
GUID-86DE9DBA-BE2F-4CC9-B447-1D2D86849EFF v2
The FunctionType parameter associates a particular instance of the function block
with a FUN. Refer to the IEC 60870-5-103 standard for details.
The InfNon parameters are used to associate each individual input signal with a
userdefined INF. Refer to the IEC 60870-5-103 standard for details.
The TypNon parameters determine if messages use absolute or relative time. This
adheres to the TYPE IDENTIFICATION (TYP) message types 1 (time-tagged
message) and 2 (time-tagged message with relative time) of the IEC 60870-5-103
standard.
The GiNon parameters determine whether a message is sent as a part of a GI reply
or not. Refer to the IEC 60870-5-103 standard for details.
17.8.10 Function commands for IEC 60870-5-103 I103CMD
17.8.10.1 Functionality
GUID-973929FE-292B-42A5-ACF9-BC95E2B16AE1 v2
I103CMD is a command function block in control direction with pre-defined
output signals. The signals are in steady state, not pulsed, and stored in the IED in
case of restart.
17.8.10.2 Identification
GUID-CFD43980-0791-40D1-9136-CF4CCC35549A v1
Function description
Function block
name
IEC 60617
identification
ANSI/IEEE C37.2
device number
Function commands for IEC
60870-5-103
I103CMD - -
17.8.10.3 Function block
GUID-C0680812-C488-4546-AA65-F590955DBF0C v1
IEC10000282-1-en.vsd
I103CMD
BLOCK 16-AR
17-DIFF
18-PROT
IEC10000282 V1 EN-US
Figure 369: I103CMD function block
Section 17 1MRK 506 382-UEN A
Station communication
752 Line distance protection REL650 2.2 IEC
Technical manual
