17.8.11.3 Function block
GUID-52D27CDA-8805-48FA-99BE-2E05A438B0C7 v1
IEC10000283-1-en.vsd
I103IEDCMD
BLOCK 19-LEDRS
23-GRP1
24-GRP2
25-GRP3
26-GRP4
IEC10000283 V1 EN-US
Figure 370: I103IEDCMD function block
17.8.11.4 Signals
PID-3788-INPUTSIGNALS v5
Table 544: I103IEDCMD Input signals
Name Type Default Description
BLOCK BOOLEAN 0 Block of commands
PID-3788-OUTPUTSIGNALS v5
Table 545: I103IEDCMD Output signals
Name
Type Description
19-LEDRS BOOLEAN Information number 19, reset LEDs
23-GRP1 BOOLEAN Information number 23, activate setting group 1
24-GRP2 BOOLEAN Information number 24, activate setting group 2
25-GRP3 BOOLEAN Information number 25, activate setting group 3
26-GRP4 BOOLEAN Information number 26, activate setting group 4
17.8.11.5 Settings
PID-3788-SETTINGS v5
Table 546: I103IEDCMD Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 255 Function type (1-255)
17.8.12 Function commands user defined for IEC 60870-5-103
I103USRCMD
17.8.12.1 Functionality
GUID-2989EAC8-20BE-46EE-93FE-C70188D0BC89 v1
I103USRCMD is a command block in control direction with user defined output
signals. These function blocks include the FunctionType parameter for each block
in the private range, and the Information number parameter for each output signal.
