PID-6735-OUTPUTSIGNALS v3
Table 369: CMMXU Output signals
Name Type Description
IL1 REAL IL1 Amplitude, magnitude of reported value
IL1RANG INTEGER IL1 Amplitude range
IL1ANGL REAL IL1 Angle, magnitude of reported value
IL2 REAL IL2 Amplitude, magnitude of reported value
IL2RANG INTEGER IL2 Amplitude range
IL2ANGL REAL IL2 Angle, magnitude of reported value
IL3 REAL IL3 Amplitude, magnitude of reported value
IL3RANG INTEGER IL3 Amplitude range
IL3ANGL REAL IL3 Angle, magnitude of reported value
PID-6738-INPUTSIGNALS v2
Table 370: VMMXU Input signals
Name Type Default Description
U3P GROUP
SIGNAL
- Group signal for voltage input
PID-6738-OUTPUTSIGNALS v2
Table 371: VMMXU Output signals
Name
Type Description
UL12 REAL UL12 Amplitude, magnitude of reported value
UL12RANG INTEGER UL12 Amplitude range
UL12ANGL REAL UL12 Angle, magnitude of reported value
UL23 REAL UL23 Amplitude, magnitude of reported value
UL23RANG INTEGER UL23 Amplitude range
UL23ANGL REAL UL23 Angle, magnitude of reported value
UL31 REAL UL31 Amplitude, magnitude of reported value
UL31RANG INTEGER UL31 Amplitude range
UL31ANGL REAL UL31 Angle, magnitude of reported value
PID-6736-INPUTSIGNALS v3
Table 372: CMSQI Input signals
Name
Type Default Description
I3P GROUP
SIGNAL
- Group signal for current input
