PID-6738-MONITOREDDATA v2
Table 392: VMMXU Monitored data
Name Type Values (Range) Unit Description
UL12 REAL - kV UL12 Amplitude,
magnitude of reported
value
UL12ANGL
REAL - deg UL12 Angle, magnitude
of reported value
UL23 REAL - kV UL23 Amplitude,
magnitude of reported
value
UL23ANGL
REAL - deg UL23 Angle, magnitude
of reported value
UL31 REAL - kV UL31 Amplitude,
magnitude of reported
value
UL31ANGL
REAL - deg UL31 Angle, magnitude
of reported value
PID-6736-MONITOREDDATA v3
Table 393: CMSQI Monitored data
Name
Type Values (Range) Unit Description
3I0 REAL - A 3I0 Amplitude,
magnitude of reported
value
3I0ANGL
REAL - deg 3I0 Angle, magnitude of
reported value
I1 REAL - A I1 Amplitude, magnitude
of reported value
I1ANGL REAL - deg I1 Angle, magnitude of
reported value
I2 REAL - A I2 Amplitude, magnitude
of reported value
I2ANGL REAL - deg I2 Angle, magnitude of
reported value
PID-6739-MONITOREDDATA v2
Table 394: VMSQI Monitored data
Name
Type Values (Range) Unit Description
3U0 REAL - kV 3U0 Amplitude,
magnitude of reported
value
3U0ANGL
REAL - deg 3U0 Angle, magnitude of
reported value
U1 REAL - kV U1 Amplitude,
magnitude of reported
value
Table continues on next page
1MRK 506 382-UEN A Section 14
Monitoring
Line distance protection REL650 2.2 IEC 549
Technical manual
