Table 425: A1RADR Non group settings (basic)
Name Values (Range) Unit Step Default Description
Operation01 Off
On
- - Off Operation On/Off
Operation02 Off
On
- - Off Operation On/Off
Operation03 Off
On
- - Off Operation On/Off
Operation04 Off
On
- - Off Operation On/Off
Operation05 Off
On
- - Off Operation On/Off
Operation06 Off
On
- - Off Operation On/Off
Operation07 Off
On
- - Off Operation On/Off
Operation08 Off
On
- - Off Operation On/Off
Operation09 Off
On
- - Off Operation On/Off
Operation10 Off
On
- - Off Operation On/Off
Table 426: A1RADR Non group settings (advanced)
Name
Values (Range) Unit Step Default Description
NomValue01 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 1
UnderTrigOp01 Off
On
- - Off Use under level trigger for analog
channel 1 (on) or not (off)
UnderTrigLe01 0 - 200 % 1 50 Under trigger level for analog channel 1
in % of signal
OverTrigOp01 Off
On
- - Off Use over level trigger for analog channel
1 (on) or not (off)
OverTrigLe01 0 - 5000 % 1 200 Over trigger level for analog channel 1 in
% of signal
NomValue02 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 2
UnderTrigOp02 Off
On
- - Off Use under level trigger for analog
channel 2 (on) or not (off)
UnderTrigLe02 0 - 200 % 1 50 Under trigger level for analog channel 2
in % of signal
OverTrigOp02 Off
On
- - Off Use over level trigger for analog channel
2 (on) or not (off)
OverTrigLe02 0 - 5000 % 1 200 Over trigger level for analog channel 2 in
% of signal
NomValue03 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 3
UnderTrigOp03 Off
On
- - Off Use under level trigger for analog
channel 3 (on) or not (off)
Table continues on next page
