Name Values (Range) Unit Step Default Description
OverTrigOp08 Off
On
- - Off Use over level trigger for analog channel
8 (on) or not (off)
OverTrigLe08 0 - 5000 % 1 200 Over trigger level for analog channel 8 in
% of signal
NomValue09 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 9
UnderTrigOp09 Off
On
- - Off Use under level trigger for analog
channel 9 (on) or not (off)
UnderTrigLe09 0 - 200 % 1 50 Under trigger level for analog channel 9
in % of signal
OverTrigOp09 Off
On
- - Off Use over level trigger for analog channel
9 (on) or not (off)
OverTrigLe09 0 - 5000 % 1 200 Over trigger level for analog channel 9 in
% of signal
NomValue10 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 10
UnderTrigOp10 Off
On
- - Off Use under level trigger for analog
channel 10 (on) or not (off)
UnderTrigLe10 0 - 200 % 1 50 Under trigger level for analog channel 10
in % of signal
OverTrigOp10 Off
On
- - Off Use over level trigger for analog channel
10 (on) or not (off)
OverTrigLe10 0 - 5000 % 1 200 Over trigger level for analog channel 10
in % of signal
GUID-E05EEC82-CB90-4E73-B9C9-4C16FD95FCBF v1
A2RADR to A4RADR functions have the same Non group settings (basic) as
A1RADR but with different numbering:
• A2RADR: Operation11 to Operation20
• A3RADR: Operation21 to Operation30
• A4RADR: Operation31 to Operation40
A2RADR to A4RADR functions have the same Non group settings (advanced) as
A1RADR but with different numbering (examples given in brackets):
• A2RADR: 11 to 20 (NomValue11, nominal value for analog channel 11)
• A3RADR: 21 to 30 (NomValue21, nominal value for analog channel 21)
• A4RADR: 31 to 40 (NomValue31, nominal value for analog channel 31)
