Name Type Values (Range) Unit Description
UnTrigStatCh30 BOOLEAN - - Under level trig for
analog channel 30
activated
OvTrigStatCh30
BOOLEAN - - Over level trig for analog
channel 30 activated
UnTrigStatCh31 BOOLEAN - - Under level trig for
analog channel 31
activated
OvTrigStatCh31
BOOLEAN - - Over level trig for analog
channel 31 activated
UnTrigStatCh32 BOOLEAN - - Under level trig for
analog channel 32
activated
OvTrigStatCh32
BOOLEAN - - Over level trig for analog
channel 32 activated
UnTrigStatCh33 BOOLEAN - - Under level trig for
analog channel 33
activated
OvTrigStatCh33
BOOLEAN - - Over level trig for analog
channel 33 activated
UnTrigStatCh34 BOOLEAN - - Under level trig for
analog channel 34
activated
OvTrigStatCh34
BOOLEAN - - Over level trig for analog
channel 34 activated
UnTrigStatCh35 BOOLEAN - - Under level trig for
analog channel 35
activated
OvTrigStatCh35
BOOLEAN - - Over level trig for analog
channel 35 activated
UnTrigStatCh36 BOOLEAN - - Under level trig for
analog channel 36
activated
OvTrigStatCh36
BOOLEAN - - Over level trig for analog
channel 36 activated
UnTrigStatCh37 BOOLEAN - - Under level trig for
analog channel 37
activated
OvTrigStatCh37
BOOLEAN - - Over level trig for analog
channel 37 activated
UnTrigStatCh38 BOOLEAN - - Under level trig for
analog channel 38
activated
OvTrigStatCh38
BOOLEAN - - Over level trig for analog
channel 38 activated
UnTrigStatCh39 BOOLEAN - - Under level trig for
analog channel 39
activated
OvTrigStatCh39
BOOLEAN - - Over level trig for analog
channel 39 activated
