Name Type Values (Range) Unit Description
Failure BOOLEAN 1=Yes
0=No
- Failure indication output
for I3
Inaccurate BOOLEAN 1=Yes
0=No
- Inaccurate indication
output for I3
Inconsistent BOOLEAN 1=Yes
0=No
- Inconsistent indication
output for I3
OldData BOOLEAN 1=Yes
0=No
- OldData indication
output for I3
OperatorBlocked BOOLEAN 1=Yes
0=No
- OperatorBlocked
indication output for I3
Oscillatory BOOLEAN 1=Yes
0=No
- Oscillatory indication
output for I3
OutOfRange BOOLEAN 1=Yes
0=No
- OutOfRange indication
output for I3
Overflow BOOLEAN 1=Yes
0=No
- Overflow indication
output for I3
Source BOOLEAN 0=Process
1=Substituted
- Source indication output
for I3
Test BOOLEAN 1=Yes
0=No
- Test indication output for
I3
Validity INTEGER 0=Good
2=Reserved
1=Invalid
3=Questionable
-
Validity indication output
I3
BadReference BOOLEAN 1=Yes
0=No
- BadReference indication
output for I4
Derived BOOLEAN 1=Yes
0=No
- Derived indication output
for I4
Failure BOOLEAN 1=Yes
0=No
- Failure indication output
for I4
Inaccurate BOOLEAN 1=Yes
0=No
- Inaccurate indication
output for I4
Inconsistent BOOLEAN 1=Yes
0=No
- Inconsistent indication
output for I4
OldData BOOLEAN 1=Yes
0=No
- OldData indication
output for I4
OperatorBlocked BOOLEAN 1=Yes
0=No
- OperatorBlocked
indication output for I4
Oscillatory BOOLEAN 1=Yes
0=No
- Oscillatory indication
output for I4
OutOfRange BOOLEAN 1=Yes
0=No
- OutOfRange indication
output for I4
Overflow BOOLEAN 1=Yes
0=No
- Overflow indication
output for I4
Source BOOLEAN 0=Process
1=Substituted
- Source indication output
for I4
Test BOOLEAN 1=Yes
0=No
- Test indication output for
I4
Table continues on next page
