17.8.4 Function status auto-recloser for IEC 60870-5-103 I103AR
17.8.4.1 Functionality
GUID-7A132276-35A2-402C-9722-6259D65998F5 v1
I103AR is a function block with defined functions for autorecloser indications in
monitor direction. This block includes the FunctionType parameter, and the
information number parameter is defined for each output signal.
17.8.4.2 Identification
GUID-7B066282-79D7-480B-BEDE-3C04F0FCBF05 v1
Function description Function block
name
IEC 60617
identification
ANSI/IEEE C37.2
device number
Function status auto-recloser for IEC
60870-5-103
I103AR - -
17.8.4.3 Function block
GUID-FAC5A3DF-73CB-4A39-A213-5C21ACA05756 v1
I103AR
BLOCK
16_ARACT
128_CBON
130_BLKD
IEC10000289-2-en.vsd
IEC10000289 V2 EN-US
Figure 363: I103AR function block
17.8.4.4 Signals
PID-3973-INPUTSIGNALS v5
Table 529: I103AR Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of status reporting
16_ARACT BOOLEAN 0 Information number 16, auto-recloser active
128_CBON BOOLEAN 0 Information number 128, circuit breaker on by
auto-recloser
130_BLKD BOOLEAN 0 Information number 130, auto-recloser blocked
17.8.4.5 Settings
PID-3973-SETTINGS v5
Table 530: I103AR Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
