Name Type Values (Range) Unit Description
BO4 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 4 status
BO5VALUE BOOLEAN 1=1
0=0
- Binary output 5 value
BO5FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 5 force
BO5 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 5 status
BO6VALUE BOOLEAN 1=1
0=0
- Binary output 6 value
BO6FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 6 force
BO6 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 6 status
BO7VALUE BOOLEAN 1=1
0=0
- Binary output 7 value
BO7FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 7 force
BO7 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 7 status
BO8VALUE BOOLEAN 1=1
0=0
- Binary output 8 value
BO8FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 8 force
BO8 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 8 status
BO9VALUE BOOLEAN 1=1
0=0
- Binary output 9 value
BO9FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 9 force
BO9 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 9 status
BO10VALUE BOOLEAN 1=1
0=0
- Binary output 10 value
BO10FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 10 force
BO10 BOOLEAN 0=Normal
1=Forced
2=Blocked
-
Binary output 10 status
BO11VALUE BOOLEAN 1=1
0=0
- Binary output 11 value
BO11FORCE BOOLEAN 0=Normal
1=Forced
- Binary output 11 force
Table continues on next page
