94 Chapter 3
Removing the VGA Module
1. See “Removing the Battery Pack” on page 46.
2. See “Removing the Upper Cover” on page 68.
3. See “Removing the Main Board” on page 88.
4. Remove the two securing screws from the VGA Module.
5. The VGA module lifts automatically from the mainboard. Remove the VGA Module as shown.
Step Size Quantity Screw Type
VGA Module M3*3 (NI) 2
