Acer eMachines E720 Series - Removing the Upper Left Saddle

Chapter 3 75
5. Remove the left speaker module as shown.
Removing the Upper Left Saddle
1. See “Removing the Upper Cover” on page 68.
2. Pull back the mylar cover to expose the top securing screw.
3. Remove the bottom securing screw.
4. While holding the cover back, remove the top securing screw.
Step Size Quantity Screw Type
Upper Left
Saddle
M2.5*4 (NL) 2
