Acer eMachines E720 Series - Removing the USB Board

Chapter 3 85
Removing the USB Board
1. See “Removing the Upper Cover” on page 68.
2. See “Removing the Bluetooth Module” on page 84.
3. Remove cable from the USB board.
4. Remove the two securing screws from the USB board and lift clear of the chassis.
Step Size Quantity Screw Type
USB board M2.5*4 (NL) 2
