Acer eMachines E720 Series - Removing the TV Board

Chapter 3 83
Removing the TV Board
1. See “Removing the Upper Cover” on page 68.
2. Disconnect the antenna and cable from the board.
3. Remove the two securing screws from the TV board.
4. Remove the TV board from the lower base.
Step Size Quantity Screw Type
TV Board M2.5*4 (NL) 2
