118 Chapter 3
3. Replace the two securing screws on the speaker module.
Replacing the Switch Board
Replacing the eKey Board
1. Insert the FFC through the Upper Cover.
1. Position the Switch Board over the screw socket. 2. Replace the single securing screw.
