Acer eMachines E720 Series - Removing the Modem Module

86 Chapter 3
Removing the Modem Module
1. See “Removing the Upper Cover” on page 68.
2. Remove securing screw from the modem module.
3. Lift the module and disconnect the modem cable as shown in the following images.
Step Size Quantity Screw Type
Modem Module M2*3 (NL) 1
