Acer eMachines E720 Series - Removing the Upper Right Saddle

Chapter 3 73
Removing the Upper Right Saddle
1. See “Removing the Upper Cover” on page 68.
2. Remove the two securing screws from the upper saddle.
3. Grasp the upper saddle and lift up to remove.
Step Size Quantity Screw Type
Upper Right
Saddle
M2*3 (NL) 2
