Acer eMachines E720 Series - Replacing the DIMM Modules

134 Chapter 3
Replacing the DIMM Modules
NOTE: To replace DIMM Module 2, first remove DIMM Module 1. In this procedure, only DIMM Module 1 is
shown.
3. Insert the HDD, interface side first, until HDD firmly slides in place.
1. Insert the DIMM Module flush with the connector and press down to lock in place.
