External Module Disassembly Process
IMPORTANT:The outside housing and color may vary from the mass produced model.
External Modules Disassembly Flowchart
The flowchart below gives you a graphic representation on the entire disassembly sequence and instructs you
on the components that need to be removed during servicing. For example, if you want to remove the main
board, you must first remove the keyboard, then disassemble the inside assembly frame in that order.
Screw List
Step Screw Quantity Part No.
Memory Cover M2.5*8 (NL) 1 86.ATA02.003
WLAN Cover M2.5*8 (NL) 1 86.ATA02.003
WLAN Module M2*3 (NL) 2 86.ATA02.005
WLAN Bracket M2*3 (NL) 1 86.ATA02.005
TV Tuner Module M2*3 (NL) 2 86.ATA02.005
HDD Carrier M3*3 (NL) 4 86.ATA02.006
ODD Module M2.5*6(NL) 1 86.ATA02.002
ODD Bracket M2*3 (NL) 3 86.ATA02.005
Remove
Express Dummy
Card
Remove
SD Dummy Card
Disconnect power
and signal cables
from system
Remove
Battery
Turn off system
and peripherals
power
Remove
Lower Covers
Remove
DIMM Modules
Remove
WLAN Board
Remove
ODD
Remove
TV Tuner Board
Remove
HDD
To Next Page
