Appendix A
Standard Printer Settings (Okidata 3410-Parallel & Serial)
Printer Mode Emulation Mode MICROLINE
Font Print Mode UTILITY
Pitch 10 CPI
Proportional Spacing NO
Style NORMAL
Size SINGLE
Symbol Sets Character Set SET I
Language Set AMERICAN
Zero Character SLASHED
Code Page USA
Rear Feed Line Spacing 6 LPI
Form Tear-Off 500 mS
Skip Over Perforation NO
Page Width 13.6”
Page Length 11”
Bottom Feed Line Spacing 6 LPI
Form Tear-Off 500 mS
Skip Over Perforation NO
Page Width 13.6”
Page Length 11”
Top Feed Line Spacing 6 LPI
Skip Over Perforation NO
Page Width 13.6”
Page Length 11”
Set-Up Graphics BI-DIRECTIONAL
Max. Receive Buffer 28K
Paper Out Override NO
Print Registration 0.00 mm
Operator Panel Functions FULL OPERATION
Reset Inhibit NO
Print Suppress Effective YES
Auto LF NO
CSF Bin Select Bin 1
Time Out Print Valid
Auto Select NO
Sensor Disable NO
Parallel I/F I-Prime Buffer Print
Pin 18 +5V
Serial I/F Parity NONE
Serial Data 7 or 8 Bits 8
Protocol RDY/BSY / XON/XOFF
Diagnostic Test NO
Busy Line SSD- / DTR / RTS
Baud Rate 19200 BPS / 9600 BPS
DSR Signal INVALID
DTR Signal READY ON POWER UP
Busy Time 200 mS
380 Dimensions 14
