Adixen ASM GRAPH - Sniffer Probe Clogged Reject Point; Starting a Sniffing Test; Ending a Sniffing Test

C 211
Operation of the leak detector
4 / 4
READY FOR CYCLE
INLET: ...
SNIFFING MODE
READY FOR CYCLE
INLET ...
GB 01362 -
Edition
02 -
September
04
Sniffing test
Starting a sniffing test
While the leak
detector is in
stand-by mode, connect the sniffer
probe
(accessory to be purchased
separately A 700) to the sniffer port
of the leak detector.
STDBY
SNIFFING MODE
PLEASE WAIT ...
The sniffing mode message
appears on the alphanumeric
display
.
The sniffing test mode is operational.
Leak value display
Ending a sniffing test
Displays are the same in hard vacuum and sniffing test modes.
Please refer to hard vacuum test mode for the displays.
STDBY
Sniffer probe clogged
reject point
Accessories A 700
Advice
Block the sniffer probe end from time to time with a finger to check
that the helium signal goes down. If not, the probe may be clogged.
Sniffer probe clogged G 200
