Adaptor for calibrated leak in sniffing
mode
An adaptor DN 16 or DN 25 for calibrated
leak has been designed for the calibration of
the
detector
with an external calibrated leak.
Accessories A
700
How to
use
the
Adaptor
Sniffer probe
adaptor ?
3
2
1
4
5
Calibrated leak
1
Place
the adaptor to your calibrated leak
used
for the calibration.
Start
a
calibration
2
Place
the sniffer probe in the calibration por
t.
3
T
ighten
the fixing srew. Follow the auto-calibration.
Calibration of the leak detector
C
300
4
Untighten
the fixing screw.
5
Remove
the sniffer probe of the calibration port. Follow the auto-
calibration.
Notes
-
Waiting 10
s
(mini) for the signal stabilization before reading of the
leak value.
- The
leak value displayed on the
LCD
consider the He of the
air
.
Example
: calibration with a leak of 2x10
-5
mbar
.l/s
The
value displayed is:
2x10
-5
+ 5x10
-6
= 2.5x10
-5
mbar.l/s
