Adixen ASM GRAPH - General Troubleshooting Guide

D 300
General troubleshooting guide
ASM 142 - 142 D - Graph D+ GB 04081 - Edition 01 - January 2009
Symptoms
D 400
Remote control
Helium signal or inlet pressure analog display abnormally lit
27
Remote Control keys inactive
28
Background
High helium background signal
47
High helium background signal (in stand-by mode)
43
High helium background signal (in hard vacuum test mode)
44
Calibration
autocal. aborted
3
autocal. required
2
Manual calibration
4
Start-up autocal. failure
31
Autocal. failure: cal. Leak year error
32
Autocal. failure: peak adjust error
37
Autocal. failure: peak locating error
36
Autocal. failure: emission loss
38
Autocal. failure: helium pollution
34
Unable to reach target value
40
Unable to start an autocalibration
39
Temperature too low/ high: autocal. failure temperature limits
33
Temperature too low/ high
51
Starting up
No display appears on the control panel
42
Nothing happens when the power is switched ON
41
Message
autocal. aborted
3
1/4
