Adixen ASM GRAPH - Access to the Board P0326 and P0330; Access to the Internal Calibrated Leak; Disassemble the Main Block

E 110
Access to the internal components
ASM 142 / ASM 142 S
d
Internal calibrated leak (
GB
00238
-
Edition 04
-
February
06
Access level 1
(continued)
Access to the inter nal
calibrated leak
Disconnect the calibrated leak temperature sensor .
 T ighten the calibrated leak clips between two fingers and pull the
calibrated leak own
T emperature
sensor
Internal calibrated leak (*)
5
Access level 2
Access to the board
P0326 and P0330
(*) ASM 142 S in option
To be applied after access level 1 is completed.
 Remove the two screws M5 and their washers
1
 Open the removable plate
1
Disassemble the main block Remove all the connections:
2 connections for
analyzer cell
1
2 quick connectors (for valves)
2
2 screws M5 + washers
1
2
2 /4
