Adixen ASM GRAPH - ACP Secondary Pump

E 111
Access to the internal components
ASM 142 D - ASM Graph D+
GB 01490
-
Edition 03
- June
08
Access level 3
ACP secondary pump
(Only ASM Graph D+)
To be applied after access level 2 is completed.
For
access to the ACP 15 secondary pump, it is necessary to remove
the leak
detector from the cart to access to the secondary pump.
Remove the 4 screws (2 others in opposite)
5 /5
