Adixen ASM GRAPH - Change of Interface

C
440
Control panel with graphic inter face
3 / 14
G
GB 02669
-
Edition 03
- June
08
Change of inter face
“Basic” mode “Advanced” mode
Standard interface Standard inter face
Graphic interface: dynamic graph Graphic interface: dynamic graph
Animated synoptic
raphic interface: memorised graph
Notes:
• Any action on one of the following keys switches the display back
to standard.
SET POINTS , SPECTRO ,
MAINTENANCE
or
• After repeated zooms or measures in a memorized graph, some
display
defects could appear when you return to the dynamic
graph.
defect example
These defects are unpredictable and no consequence. If a graph is
recording,
these defects will not be recorded.
