Adixen ASM GRAPH - Pipes - Connections - Seals

F 1100
Pictures of components
GB - DB02 -
03/2009
064600 G012
VACUUM SILICON GREASE ( l 00
G BOX)
«
G015
VALVE BLOCK, UPPER - l 42/ l 42D
«
G016
VALVE BLOCK, LOWER -
l 42/ l 42D/ l 42S
076112 G029
SHOCK ABSORBER - C
A458833 G037
FLAT L-BRACKET BLOCK-FRAME
F 800 Pipes - Connections - Seals
«
H001
TUBING, PVC; D 4 x l MM
A458324 H005
CONNECTOR FOR PLASTIC TUBE
4 x
l
082988 H006
BODY FEMALE CONNECTOR G l /8
RBE03.2 l 00
068370 H007
BELLOWS, SS; DN25KF L 250 MM
083333 H020
CLAMP DN l 0/ l 6KF
075989 H021
SILENCER l /8 70 MICRONS
083264 H026
CLAMP DN20/25KF
068196 H027
FLANGE, BLANK; SS DN25KF
083267 H028
CLAMP DN32/40KF
087163 H030
CLAMP DN50KF
082775 H035
MALE UNION BSPT F3BPL 2.7/4
- l /8
106022 H037
O'RING DN25KF HNBR
106023 H038
O'RING DN40KF HNBR
106021 H040
O'RING DN l 6KF HNBR
100983 H046
DIAPHRAGM DN25KF - D l 0 MM
068224 H047
CENTERING RING DN25KF
068226 H048
CENTERING RING DN40KF
072857 H050
FILTER, DN25KF; 70 MICRONS
067636 H051
FILTER, DN40KF
103395 H059
FILTER, INLET
106828 H063
SEAL, INDIUM; DN25KF D l 0 MM
106819 H064
SEAL, INDIUM; DN25KF V A T
106818 H069
SEAL, INDIUM; DN l 6KF V A T
A459308 H070
SEAL, INDIUM; DN40KF WITH FILTER
068381 H071
CLAMP, CHAIN; ALUMINIUM
DN20/25KF
6 /9
