Adixen ASM GRAPH - Graphic Interface Setting; Menus Description

C
440
Control panel with graphic inter face
7 / 14
GB 02669
-
Edition 03
- June
08
Graphic inter face
setting
A simple press on the dynamic graph allows access to the setting
menu.
Menus description
8 8
5 6 7
2
1 1
3
2 3
4
7
4
“Advanced“ mode “Basic“ mode
1
Selected parameter modification
2
Graph type selection : vertical or horizontal
- Time precision required > horizontal
- Measure precision and speed required >vertical
- If we switch from a vertical graph to a horizontal graph, or
vice-versa, all the dynamic graph points will be erased.
example: the same curve with both graph types.
Horizontal V er tical
