You can enlarge as many
times
as you want until the displayed
period is equal to the sampling time
set
(until 2 points visible on the
graph).
•
You can only enlarge the
complete
decades: you can not enlarge
inside a decade.
Point
measure
The
memorized graph allows you to give the exact
measure
of every
memorized graph point at a “t” time.
•
Press
on key
1
.
1
•
A target
2
appears at the
screen
center.
3
3
3
x
2
4
The
target is the curve point to measure.
It is possible to change the target: move the axes with the finger or
arrows
3
.
•
To
switch the target from the helium signal curve to the inlet
pressure
curve,
press
the key 4
.
5
6
x x
4
>
helium signal
value 6 or
inlet
pressure
5
>
measure
time (t)/recording start
