Definition
The
correction factor is
used
to display the helium signal (changing
unit for example).
The
correction factors applied to the digital display with
respect
to the
external calibration are:
•
VACUUM COR in
gross
leak
test
mode,
•
SNIF
COR in sniffing
test
mode.
The
VACUUM/SNIF COR
values
are automatically adjusted according
to helium signal fluctuations.
These
correction factors are memorized until another external
calibration is validated.
They
can be activated, deactivated or modified.
The
correction factors are automatically calculated by the external
calibration but it is also possible to enter
them
manually
C
303
Activate/Deactivate
the
correction
factor
VACUUM/SNIF COR
Adjustment
There
are 2 possible
procedures
depending on which authorized
level: level
3
and
4
.
Procedure
with user
level
3
Adjustment
C
110
on
off
VACUUM C
O
R
Adjustment
SNIF COR
