A help for control panel utilization/access.
Operating principle of the control panel
C
110
Access
to level 4 - Password
C
130
Setting
and
maintenance
part
presentation
of the control panel
Access
to
parameters
and
parameters
active
depending on authorization
C
120
Summary
of screens
Complete displays list with
access
way and
associated
sheet
C
140
Choices
proposed to
the operator
The
operator can
connect
the leak detector:
-
to the vent air function,
-
the gas line option (ASM 182 TD+ only).
At any time, during or after
test,
the inlet
status
is displayed
on the
LCD
and it is possible to control it (except for
user
level
interface
1
).
The
proposed default value is “off” (= valve closed).
Inlet: Air Vent
Air vent purpose
At the end of a
test
cycle, 2
possibilities
are available:
-
venting (putting back to
atmospheric
pressure)
-
not venting (keeping under
vacuum)
the part or installation tested.
This
one can be made in a automatic or forced
way
.
That
is why, the operator should program the following parameters:
-
air vent at the end of a
test
cycle (“air
off”/”air on”)
-
activation of this air vent
(“automatic”/”operator”).
