Adixen ASM GRAPH - Pipes - Connections - Seals ASM 142 D

Alcatel Vacuum Technology France - User's Manual ASM 142 D
TRM DB02 03/2009
13
F 800
Pipes - Connections - Seals
ASM 142 D
Ref Descriptio n
P/N
Qty
Remarks
H026
CLAMP DN20/25KF
083264
1
H037
O'RING DN25KF HNBR
106022
1
H038
O'RING DN40KF HNBR
106023
1
H040
O'RING DN16KF HNBR
106021
1
H046 DIAPHRAGM DN25KF - D 10 MM
100983
1
H047
CENTERING RING DN25KF
068224
1
H048
CENTERING RING DN40KF
068226
1
H063
SEAL, INDIUM; DN25KF D 10 MM
106828
1
H064
SEAL, INDIUM; DN25KF VAT
106819
1
H069
SEAL, INDIUM; DN16KF VAT
106818
1
H070
SEAL, INDIUM; DN40KF WITH FILTER
A459308
1
H071
CLAMP, CHAIN; ALUMINIUM DN20/25KF
068381
1
H072
MOLD FOR LEAD SEAL
072427
1
H074
SEAL, ELASTOMER; SPECIAL CELL
102823
1
H094
LEAD WIRE 10 M - 0.8 MM
083478
1
* Contact customer services
